Chromebooks have a reputation of being little, secure devices:

  • Verified Boot ties the integrity of the OS to the underlying hardware: Google’s marketing material describes it as “a read-only operating system”.
  • Then, defense in depth increases its robustness: The Chrome sandbox, the OS userspace, the kernel, the firmware, and lastly the hardware.

In other words: the system should be clean at boot and remain clean while running. As a user, this means I can get a Chromebook and powerwash it (lingo for a deep but fast wipe) to start from a reasonably trustworthy computing base. Compromising it should be relatively hard (thanks to defense in depth). And, worst case, a reboot shall return it to a clean state.

On paper, this is awesome! It makes Chromebooks the go-to for most security-sensitive tasks. However, turning a powerwashed device into a productive environment requires an initial setup process, logging into each required online service, setting up all tools, and finally getting to work.

Ideally, instead, I would like to skip all configuration and be productive as quickly as possible. That way, I could periodically throw away any persisted state and restart from scratch. I could spin up segregated environments (e.g., one for personal life, one for work, or even one for each project), and even quickly get them running on multiple machines.

This post describes my approach to this goal: reproducible, throwaway containers running securely under ChromeOS.

# The requirements

I don’t need much to be productive: a web browser and a shell. The browser is my gateway to most apps and services. Even when there are alternatives (e.g. native or Electron apps), I prefer to rely on the browser to add defense in depth. The shell usually provides everything else I need, including an editor and access to other hosts.

A productive shell should come as ready as possible: for instance, git should know who I am and how I prefer to fetch branches. It should be easy to configure, audit, and (re)build from scratch. Deploying it to a clean device should be fast (minutes). Importantly, it should not bundle any secret (e.g., passwords or cryptographic keys) or confidential information, nor should it have access to any long-lived credential either.

The lack of secrets and credentials is important for safety: if the environment is compromised while at rest, there is nothing to exfiltrate. Plus, we do not need to worry about how we deliver the container image, where we store it, if it leaks, and when to dispose it. If, instead, if the compromise happens at runtime (e.g., through a malicious executable), then the attacker should not be able to access any long-lived credential (e.g., an SSH key).

# The solution

My solution largely relies on:

  1. Hardware keys, holding login credentials and cryptographic keys.
  2. NixOS containers, running under ChromeOS’ Crostini.

# Hardware keys

Hardware keys create a security boundary between the secrets and the environment. They allow me to securely “bring” secrets, while ensuring that they never leave the hardware device and are never exposed directly to the environment.

Through hardware keys I can:

  1. Login to online services (thanks to WebAuthn and passkeys).
  2. Prove second factors (“something I have”).
  3. Authenticate to other hosts (through SSH) and sign messages.

Some online services now allow passwordless login through passkeys. This means that I don’t need to type my username or password: I just visit their website through Chrome, unlock the hardware key through its PIN, and login.

In some cases, a hardware key can only be used as a second factor (in the browser). When that happens, I can still leverage it to decrypt the password from a vault (e.g. using passage in the shell, or authenticating to a password manager with a passkey). As more services embrace passkeys, the need for passwords will hopefully become less frequent.

Lastly, the hardware key holds SSH keys used both for authentication (ssh) and signing (e.g., git commit) while in the shell.

# NixOS containers

One of the killer features of Chromebooks is that they have good support for running Linux without compromising on security. Technically, a system called Crostini runs a Linux VM (booting a hardened kernel), which in turn runs lxc containers. By default, ChromeOS ships a debian container.

What makes Crostini great (e.g., when compared to SSH into a remote system) is that it has first-class integration with ChromeOS. You can run Linux GUI apps and they will show up alongside all other Chrome apps; you can open a URL in the Linux container and it will open in Chrome; you can copy to clipboard in Linux and it will populate ChromeOS’ clipboard; ChromeOS will even forward most ports from localhost to the container.

The default debian container ships a few services that make that magic happen. Here are the two I have found the most useful:

  • garcon enables bidirectional communication between ChromeOS and the container. This allows using the Terminal to get to a container console, handling URLs, browsing container files through the Files app, etc.
  • sommelier allows the container to run GUI applications (and clipboard management).

The obvious downside of the debian container is that it is “vanilla” and it requires heavy customization. That’s where NixOS makes a difference: it makes it easy to build a container that ships required tools (think git, ssh, but even the AWS CLI) and all their required configuration (.dotfiles, profiles, etc.).

To get NixOS running under Crostini:

  1. I first prepared a custom NixOS image that included my dotfiles and the tools I usually need to be productive.
  2. I then added garcon and sommelier, to make it play nicely with ChromeOS.
  3. Lastly, I figured out how to ship it to the Chromebook and run it.

# How-to: Preparing the image

There are a few ways to prepare a lxc image shipping your NixOS configuration. I won’t go into details here, since Nix itself is a pretty deep rabbit hole and it would take more than one blog post to do a good job at explaining it.

In my case, I applied nixos-generators to my Nix configuration to build the lxc RootFS and its associated metadata (both are .tar.xz) files.

Then, I prepared a crostini.nix module to provide garcon and sommelier through systemd. The ChromeOS source code and the cros-container-guest-tools-git AUR package were invaluable in making this happen.

Click to toggle the source for the Crostini NixOS module.
{
  modulesPath,
  lib,
  pkgs,
  ...
}:

let
  cros-container-guest-tools-src-version = "4ef17fb17e0617dff3f6e713c79ce89fee4e60f7";

  cros-container-guest-tools-src = pkgs.fetchgit {
    url = "https://chromium.googlesource.com/chromiumos/containers/cros-container-guest-tools";
    rev = cros-container-guest-tools-src-version;
    outputHash = "sha256-Loilew0gJykvOtV9gC231VCc0WyVYFXYDSVFWLN06Rw=";
  };

  cros-container-guest-tools = pkgs.stdenv.mkDerivation {
    pname = "cros-container-guest-tools";
    version = cros-container-guest-tools-src-version;

    src = cros-container-guest-tools-src;
    installPhase = ''
      mkdir -p $out/{bin,share/applications}

      install -m755 -D $src/cros-garcon/garcon-url-handler $out/bin/garcon-url-handler
      install -m755 -D $src/cros-garcon/garcon-terminal-handler $out/bin/garcon-terminal-handler
      install -m644 -D $src/cros-garcon/garcon_host_browser.desktop $out/share/applications/garcon_host_browser.desktop
    '';
  };

in
{
  imports = [
    # Load defaults for running in an lxc container.
    # This is explained in: https://github.com/nix-community/nixos-generators/issues/79
    "${modulesPath}/virtualisation/lxc-container.nix"
  ];

  # The eth0 interface in this container can only be accessed from the host.
  networking.firewall.trustedInterfaces = [ "eth0" ];

  # Disabling IPv6 makes the boot a bit faster (DHCPD)
  networking.enableIPv6 = false;
  networking.dhcpcd.IPv6rs = false;
  networking.dhcpcd.wait = "background";

  # `boot.isContainer` implies NIX_REMOTE = "daemon"
  # (with the comment "Use the host's nix-daemon")
  # We don't want to use the host's nix-daemon.
  environment.variables.NIX_REMOTE = lib.mkForce "";

  # Suppress daemons which will vomit to the log about their unhappiness
  systemd.services."console-getty".enable = false;
  systemd.services."getty@".enable = false;

  # Disable nixos documentation because it is annoying to build.
  documentation.nixos.enable = lib.mkForce false;

  # Make sure documentation for NixOS programs are installed.
  # This is disabled by lxc-container.nix in imports.
  documentation.enable = lib.mkForce true;

  environment.systemPackages = [
    cros-container-guest-tools

    pkgs.wl-clipboard # wl-copy / wl-paste
    pkgs.xdg-utils # xdg-open
  ];

  environment.etc = {
    # Required because `tremplin` will look for it.
    # Without it, `vmc start termina <container>` will fail.
    "gshadow" = {
      mode = "0640";
      text = "";
      group = "shadow";
    };

    # TODO: Even empty, this will stop `sommelier` from erroring out.
    "sommelierrc" = {
      mode = "0644";
      text = ''
        exit 0
      '';
    };
  };

  system.activationScripts = {
    # Activating sommelier-x will rely the bind-mount Xwailand executable. As
    # far as I could debug, this path can't be controlled through env and would
    # require re-compiling Xwayland (which is also dynamically loaded by the
    # sommelier executable).
    #
    # Same for the `sftp-server` launched by `garcon`.
    #
    # These are ugly HACKs, but they work
    xkb = "ln -sf ${pkgs.xkeyboard_config}/share/X11/ /usr/share/";
    sftp-server = ''
      mkdir -p /usr/lib/openssh/
      ln -sf ${pkgs.openssh}/libexec/sftp-server /usr/lib/openssh/sftp-server
    '';
  };

  # Load the environment populated from `sommelier`, e.g. `DISPLAY`.
  environment.shellInit = builtins.readFile "${cros-container-guest-tools-src}/cros-sommelier/sommelier.sh";

  # Taken from https://aur.archlinux.org/packages/cros-container-guest-tools-git
  xdg.mime.defaultApplications = {
    "text/html" = "garcon_host_browser.desktop";
    "x-scheme-handler/http" = "garcon_host_browser.desktop";
    "x-scheme-handler/https" = "garcon_host_browser.desktop";
    "x-scheme-handler/about" = "garcon_host_browser.desktop";
    "x-scheme-handler/unknown" = "garcon_host_browser.desktop";
  };

  systemd.user.services.garcon = {
    # TODO: In the original service definition this only starts _after_ sommelier.
    description = "Chromium OS Garcon Bridge";
    wantedBy = [ "default.target" ];
    serviceConfig = {
      ExecStart = "/opt/google/cros-containers/bin/garcon --server";
      Type = "simple";
      ExecStopPost = "/opt/google/cros-containers/bin/guest_service_failure_notifier cros-garcon";
      Restart = "always";
    };
    environment = {
      BROWSER = (lib.getExe' cros-container-guest-tools "garcon-url-handler");
      NCURSES_NO_UTF8_ACS = "1";
      QT_AUTO_SCREEN_SCALE_FACTOR = "1";
      QT_QPA_PLATFORMTHEME = "gtk2";
      XCURSOR_THEME = "Adwaita";
      XDG_CONFIG_HOME = "%h/.config";
      XDG_CURRENT_DESKTOP = "X-Generic";
      XDG_SESSION_TYPE = "wayland";
      # FIXME: These paths do not work under nixos
      XDG_DATA_DIRS = "%h/.local/share:%h/.local/share/flatpak/exports/share:/var/lib/flatpak/exports/share:/usr/local/share:/usr/share";
      # PATH = "/usr/local/sbin:/usr/local/bin:/usr/local/games:/usr/sbin:/usr/bin:/usr/games:/sbin:/bin";
    };
  };

  systemd.user.services."sommelier@" = {
    description = "Parent sommelier listening on socket wayland-%i";
    wantedBy = [ "default.target" ];
    path = with pkgs; [
      systemd # systemctl
      bash # sh
    ];
    serviceConfig = {
      Type = "notify";
      ExecStart = ''
        /opt/google/cros-containers/bin/sommelier \
                      --parent \
                      --sd-notify="READY=1" \
                      --socket=wayland-%i \
                      --stable-scaling \
                      --enable-linux-dmabuf \
                      sh -c \
                          "systemctl --user set-environment ''${WAYLAND_DISPLAY_VAR}=$''${WAYLAND_DISPLAY}; \
                           systemctl --user import-environment SOMMELIER_VERSION"
      '';
      ExecStopPost = "/opt/google/cros-containers/bin/guest_service_failure_notifier sommelier";
    };
    environment = {
      WAYLAND_DISPLAY_VAR = "WAYLAND_DISPLAY";
      SOMMELIER_SCALE = "1.0";
    };
  };

  systemd.user.services."sommelier-x@" = {
    description = "Parent sommelier listening on socket wayland-%i";
    wantedBy = [ "default.target" ];
    path = with pkgs; [
      systemd # systemctl
      bash # sh
      xorg.xauth
      tinyxxd
    ];
    serviceConfig = {
      Type = "notify";
      ExecStart = ''
        /opt/google/cros-containers/bin/sommelier \
          -X \
          --x-display=%i \
          --sd-notify="READY=1" \
          --no-exit-with-child \
          --x-auth="''${HOME}/.Xauthority" \
          --stable-scaling \
          --enable-xshape \
          --enable-linux-dmabuf \
          sh -c \
              "systemctl --user set-environment ''${DISPLAY_VAR}=$''${DISPLAY}; \
               systemctl --user set-environment ''${XCURSOR_SIZE_VAR}=$''${XCURSOR_SIZE}; \
               systemctl --user import-environment SOMMELIER_VERSION; \
               touch ''${HOME}/.Xauthority; \
               xauth -f ''${HOME}/.Xauthority add :%i . $(xxd -l 16 -p /dev/urandom); \
               . /etc/sommelierrc"
      '';
      ExecStopPost = "/opt/google/cros-containers/bin/guest_service_failure_notifier sommelier-x";
    };
    environment = {
      # TODO: Set `SOMMELIER_XFONT_PATH`
      DISPLAY_VAR = "DISPLAY";
      XCURSOR_SIZE_VAR = "XCURSOR_SIZE";
      SOMMELIER_SCALE = "1.0";
    };
  };

  systemd.user.targets.default.wants = [
    "[email protected]"
    "[email protected]"
    "[email protected]"
    "[email protected]"
  ];
}


After rebuilding the image to include this module, the only thing missing is uploading it somewhere so that we can later fetch it from the Chromebook. The simplest solution I have found is to host a “Public” LXD image server, behind Tailscale (so that is not, in fact, public):

Public LXD servers

LXD servers that are used solely to serve images and do not run instances themselves.

To make a LXD server publicly available over the network on port 8443, set the core.https_address configuration option to :8443 and do not configure any authentication methods (see How to expose LXD to the network for more information). Then set the images that you want to share to public.

If you are using a NixOS host, enabling lxd is easy:

virtualisation.lxd.enable = true;

Then, enable the image server as follows:

# `lxd` can't be configured declaratively in NixOS, go figure!
sudo lxc config set core.https_address :8443

You can now import the image with:

# Replace `lxc-metadata` and `lxc` with the directories where you built the metadata and the RootFS.
lxc image import --public --alias lxc-nixos ${lxc-metadata}/tarball/*.tar.xz ${lxc}/tarball/*.tar.xz

We are now ready to deploy the image to the Chromebook.

# How-to: Deploying the image

If you haven’t done it yet, configure Linux. When asked, choose the same username you will use within the container. I usually use 32GB of storage.

Now open crosh (ctrl, alt, t), then:

# Not strictly required, but better start clean.
vmc destroy termina
vmc start termina

Connect to Tailscale (install the app from the Play Store, use the hardware key to authenticate). Then, from inside termina:

# Assuming `tropic` is the hostname of the `lxd` server we have configured before.
lxc remote add tropic https://tropic:8443 --public
# Ensure you can see the image listed.
lxc image list tropic:
# Download the image and setup the container
lxc init tropic:lxc-nixos lxc-nixos --config security.nesting=true

I have seen a few guides recommending --config security.privileged=true.

Don’t do it! If you do, you will spend a couple hours (as I did) trying to figure out why USB devices correctly show up in lsusb but then error with “permission denied” when you try accessing them. In my experience, there is no need for that flag.

The security.nesting=true, instead, is required to run nix in the container. It is part of the default configuration that Crostini uses to init containers, and it is the right choice.

Downloading the image will unfortunately take some time (termina seems to download it at about 1.25 MB/s). I try to keep the image size to a minimum to make this step fast.

You can now start the container and, after a few seconds, it should get an IP through DHCP:

lxc start lxc-nixos

# Peek at the console logs, if you want
lxc console --show-log lxc-nixos

# Wait until `lxc list` shows an IP.
lxc list

At this point you can exec into the container and play around with it:

lxc exec lxc-nixos bash

We are not done yet, though! First, we don’t need to be logging in as root. Second, garcon will not work yet, because it is missing a required file: /dev/.container_token. As far as I can tell, to get .container_token we need to start the container from crosh. So:

# From Termina (ctrl-d if you are still in `lxc-nixos`)
lxc stop --force lxc-nixos

# From crosh (ctrl-d from `termina`)
# This will ensure `/dev/.container_token` exists within the container
vmc container termina lxc-nixos

This will error out telling you that the container cannot be found. Fear not! The container has started in the background and you’ll get a shell (by re-running the same command) once it gets an IP. Now you should be able to see garcon and sommelier running correctly.

vmc container termina lxc-nixos

# Now, in `lxc-nixos`
systemctl --user status garcon.service
systemctl --user status [email protected]
systemctl --user status [email protected]

We can also make a couple of tests:

# This should populate your ChromeOS clipboard (you can check it with launcher-v or by pasting somewhere).
# Under the hood, it uses `sommelier` through the Wayland protocol.
echo "Clipboard works!" | wl-copy

# This should have a pair of goggly eyes pop on your screen and is testing X proxying through `sommelier-x`
nix run nixpkgs#xorg.xeyes

# How-to: USB forwarding

In order to use hardware keys within the container, we will also need to set up USB forwarding.

Every time you plug a USB device in, ChromeOS should prompt you whether you want to connect it to Android or Linux. That has never worked for me, so I just went the CLI way.

Insert the device and then navigate to chrome://usb-internals. In the devices tab, note the Bus number and Port number of your device.

Now open a new crosh shell and run the following:

# Replace <bus> and <port> with the Bus and Port number from above.
vmc usb-attach termina <bus>:<port> lxc-nixos

Running lsusb within the container should show the device ready for use. Occasionally, the device was showing up in lsusb but the hardware key wouldn’t work. In those cases, a reboot of the termina VM typically fixes things.

# How-to: SSH into the container

If your container ships an SSH server, you can also use the built-in Terminal application to SSH into it. This is useful in case you want to use agent forwarding, for example, and because it leaves the USB hardware key usable from Chrome as well.

Open the Terminal application and configure a new SSH connection. Fill in <username>@lxc-nixos.termina.linux.test for the command. Add the following to the SSH relay server options field to enable authentication through the hardware key:

--ssh-agent=gsc --ssh-client-version=pnacl

Connecting should trigger a prompt for your hardware key PIN. Insert it, touch the key if you need it, and you should be in.

I have noticed this to be hit-or-miss. Sometimes it fails to authenticate transiently and I have to try re-connecting. Other times, it won’t show the PIN prompt. Disconnecting and re-connecting the hardware key sometimes helps (sigh!).

# How-to: Root login

See this post.

# Conclusion

Software-wise, my crostini.nix module does most of the heavy lifting for the things I actually need to work. I haven’t tested hardware acceleration, audio, and there’s probably a few more things that do not work yet (when compared to debian). But I can always add those things when the need arises. Clipboard sharing between Chrome and Crostini is probably the feature I am using the most, in addition to opening URLs in Chrome from the container through garcon.

Hardware-wise, I feel that Chromebooks are great “couch-computing” or travel devices. They are underpowered with respect to other machines (e.g., an M4 MacBook). But they are lighter, cheaper, and their battery is OK considering they are “Linux” devices (I can probably do 6 hours on mine). I wish the display was a bit brighter, especially under direct light.

Overall, after using this setup for a few weeks I am satisfied with it – I even wrote this blog post on a Chromebook! It does most of what I was looking for, strikes a good security posture, and I like being able to go from zero to a productive environment in a few minutes (where most of the time is idle, waiting for the lxc image to download). Once the container boots, I immediately feel at home. I can quickly get ahead and write my thoughts, hack on a new project, or put off the occasional fire at work. Having a full system bottled-in and ready to go also gives me confidence I could somehow recover in case of disaster (think fire, natural disaster, theft, etc.), ensuring that I do not rely on a single point of failure. Lastly, this setup is trivial to deploy to a different system: I have had some fun playing with AI agents in a qemu VM built using the same tools.

Thanks for reading, and ‘til next time!

The ChromiumOS team is experimenting with a way (codename baguette) to run containers without a KVM. If that happens and this guide becomes outdated, reach out! We will figure out how to make it work there as well.

# References
